Add more functionality to your self-service environments with a hybrid card reader.
Unparalleled Versatility
Consider it the heart of your payment system. The UX 300/301 accepts MSR, EMV or contactless payment types, independent of PIN-based transactions.
Purposeful Design
The dependable and weatherproof anti-vandalism enclosure provides maximum protection against the elements.
Maximum Security
Secure to the core, the device is tamper-resistant and equipped with PCI 5.X security standard certification.
Payment Gateway
Secure Payment Acceptance
Fast Payments
All Card Schemes
Perfect for Petro and Vending
Weatherproof Protection
Tamper-Resistant Design
We can help you get started.
Device Specifications
Display
- Optional Display with UX100 or UX115
Multimedia
- Buzzer
User Interface
- Configurable Service Button
Card Readers
- Landed Smart Card
- Magstripe ISO 7810, 7811, 7813
- Smart Card EMVCo Approved
Contactless
- Optional: EMVCo Approved with UX400
Memory
- 128MB RAM + 256MB Flash
- Optional 256 MB RAM + 512 MB Flash
Operating System
- Verifone Secure OS, VOS
Processor
- ARM11 32-bit RISC, 400 MHz
Security
- PCI PTS 5.x Approved
Connections
- Contactless Antenna Digital
- Contactless Antenna RF
- LAN 10/100 Base-T
- Optional: Additional 4 USB TypeA + 2 RS232
- Optional: Additional LAN 10/100 Base-T
- Optional: MDB
- Optional: RS485
- RS232
- USB Micro-B
- USB Type-A
- USB Type-B
Power
- Low Power Modes
- Optional Rating 24V 3.7A, 6 Pin Socket
- Optional Rating 9-43V 1.2-0.3A, 6 Pin Socket
- Optional Rating 9-43V 2.4-0.5A, 6 Pin Socket
- Rating 9-12V 1-0.7A, 4 Pin Socket
Physical
- 167mm (13mm front projection) L × 100mm W × 71mm H
- Cutout 74mm × 62mm
Environmental
- IK Rating IK09
- IP Rating IP34
- Operating Temperature: -20° to 70° C (-4° to 158° F)
- Relative Humidity: 10% to 90%, Non-condensing
- Storage Temperature: -25° to 70° C (-13° to 158° F)
Other Standard Features
- Card Slots 2 SAM
- Real-time Clock
Product
Frequently Asked Questions
The UX300 is a card reader designed for secure and efficient payment acceptance. It works seamlessly with or without the UX100 PIN Pad and offers flexibility in how you accept payments.
The Verifone UX300 supports a wide range of payment methods via chip and magnetic stripe cards. In combination with the UX Series PIN Pad and NFC rader, it also supports PIN, contactless and mobile wallets such as Apple Pay and Google Pay.
The Verifone UX300 is equipped with advanced security features, including end-to-end encryption, and EMV compliance. It helps protect sensitive customer data and ensures secure transactions.
Yes, the UX300 is designed to integrate with a variety of point-of-sale systems. It can communicate with your POS software ensuring a smooth and streamlined payment experience.
UX300 is tamper-resistant design features anti-vandalism enclosure that can withstand an impact of up to 10 Joules. Furthermore, it is weatherproof enclosure provides top-level protection against dust, liquids and other harmful substances, withstanding IP34.
To get started, simply reach out to our sales team. Our team will provide you with the necessary information and guide you through the process of integrating the card reader into your setup.
End-to-End Solutions
UX100
Pair the Verifone UX300 with the Verifone UX100 to optimize your transaction functionality.
Gateways
Use our secure-transaction processing solution to deliver fast and scalable payments.
Device Management
Increase ROI and create exceptional customer experiences with a well-managed estate
