An excellent choice for your outdoor unattended payment scenarios. Weather tolerant, user friendly and built-for-purpose design.
Investment protection
PIN pad built for exceptional performance and extreme durability, ideal for off-street parking meters, ticketing machines, and more.
Purposeful design
The embossed & color-marked buttons enable friendly and intuitive use, while a high contrast display on the UX100 simplifies readability in sunlight.
Maximum security
Secure to the core, the device is tamper-resistant and equipped with PCI 5.X security standard certification.
Payment Gateway
Secure Payment Acceptance
Fast Payments
All Card Schemes
Perfect for Petro and Vending
Weatherproof Protection
We can help you get started.
Device Specifications
Enhance your self-service experience
Display
- 2.4" Screen
- LED Backlight
- Monochrome LCD
- Resolution 128 x 64
User Interface
- Keypad Durability: 2,000,000 Presses Each
- Tactile 16-Key Keypad
Processor
- ARM 32-bit RISC
Security
- PCI PTS 5.x Approved
Connections
- USB Type-B
Power
- Low Power Modes
- Rating 5V, 1.2A, USB Type-B
Physical
- 33mm (5mm front projection) L × 108mm W × 142mm H
- Cutout 83mm × 121mm
Environmental
- IK Rating IK09
- IP Rating IP65
- Operating Temperature: -20° to 70° C (-4° to 158° F)
- Relative Humidity: 10% to 90%, Non-condensing
- Storage Temperature: -25° to 70° C (-13° to 158° F)
Frequently Asked Questions
UX100 is payment PIN pad for secure and convenient unattended payment processing. It combines robust design with a simple interface, making it an ideal choice for businesses in various industries.
UX100 is a PIN pad, but in combination with UX300, it supports a wide range of payment methods, including chip and PIN, contactless (NFC) payments, magnetic stripe cards, and mobile wallet payments such as Apple Pay and Google Pay.
The UX100 is equipped with advanced security features, including end-to-end encryption, secure PIN entry, and EMV compliance. It helps protect sensitive customer data and ensures secure transactions.
UX100 integrates with a variety of point-of-sale systems. It can communicate with your POS software, allowing for easy integration and streamlined operations.
UX100 has a durable, metal front plate and weatherproof enclosure provide top-level protection against dust, liquids and other harmful substances withstanding IP65. Its anti-vandalism enclosure can withstand an impact up to 10 Joules (IK09)
UX100 has multple service options. Contact us for more details.
Get started with UX100 by simply contacting our sales team. Our team will guide and assist you in selecting the right configuration for your business needs and provide you with all the necessary information to begin using the terminal.
End-to-End Solutions
UX300
Pair the UX100 with the UX300 card reader to optimize your transaction functionality.
Gateways
Use our secure-transaction processing solution to deliver fast and scalable payments.
Device Management
Increase ROI and create exceptional customer experiences with a well-managed estate
